Use length-delimited, byte-aligned codecs

[pm47]

All LN protocol message must be stored as length-delimited, because they may have arbitrary trailing data.

Took the opportunity to restore byte alignment. It was mainly due to the use of single-bit bool codec.

The goal is to play safe and have simple codecs, so the existing codecs have been kept and moved to a Legacy inner object.

This is an alternative to #1239.

[pm47]

The shaChainCodec isn't byte aligned, and there may be room for optimization there. cc @sstone

[t-bast]

I think we should make it byte-aligned, but the question is whether to do it "outside" (what you just did), or inside the shachain codec (use bool8 instead of bool)?

[pm47]

Apparently we can be more optimal, the codec should naturally be byte-aligned. Since this is sensitive code I'd rather leave that optimisation to another PR.

[pm47]

I removed the compatibility codec since the new codec will never use it.

[pm47]

My plan for tests would be to generate a bunch of channel data before this patch (maybe with scalacheck generators @t-bast?) and their java object checksum.

I would then apply this change, read-then-write-then-read-again the data, and make sure the three checksums are equal.

I think that would bring solid assurance that we don't have a regression.

[pm47]

So I validated the change by following the procedure decribed in my previous comment. I'm using an sqlite table with two columns: scodec-serialized and java-serialized, generated on a pre-migration branch. Then on the post-migration branch, I make sure that read(scodec) == read(java) and read(write(read(scodec))) == read(java).

I ended up using three data sets:

• randomly generated data, using scalacheck (code here). Caveats: a few fields were empty or hardcoded (transactions, pending commitment changes).
• testnet and mainnet node data, using this code:

  test("nonreg length-delimited reference data generation") {
    val sqlite = DriverManager.getConnection(s"jdbc:sqlite:${new File("endurance_before.sqlite")}")
    sqlite.createStatement().executeUpdate("CREATE TABLE data (scodec BLOB NOT NULL, java BLOB NOT NULL)")

    val read_sqlite = DriverManager.getConnection("jdbc:sqlite::resource:eclair.sqlite.endurance.bak")
    val rs = read_sqlite.createStatement().executeQuery("SELECT data FROM local_channels")
    var count = 0
    while (rs.next()) {
      val scodec = BitVector(rs.getBytes("data"))
      val d = ChannelCodecs.stateDataCodec.decode(scodec).require.value
      val bos = new ByteArrayOutputStream()
      val oos = new ObjectOutputStream(bos)
      oos.writeObject(d)
      oos.close()
      val java = bos.toByteArray
      val statement = sqlite.prepareStatement("INSERT INTO data VALUES (?, ?)")
      statement.setBytes(1, scodec.toByteArray)
      statement.setBytes(2, java)
      statement.execute()
      count = count + 1
    }
    println(s"processed $count channels")
  }

This is the actual test:

test("nonreg length-delimited migration") {
    val sqlite = DriverManager.getConnection(s"jdbc:sqlite:${new File("endurance_before.sqlite")}")
    val rs = sqlite.createStatement().executeQuery("SELECT * FROM data")
    var count = 0
    while (rs.next()) {
      val scodec = ByteVector(rs.getBytes(1)).bits
      val java = rs.getBytes(2)
      val d_scodec = ChannelCodecs.stateDataCodec.decode(scodec).require.value match {
        case d: DATA_WAIT_FOR_FUNDING_CONFIRMED => d.copy(waitingSince = 42000)
        case d: DATA_CLOSING => d.copy(waitingSince = 123456789)
        case d => d
      }
      val bis = new ByteArrayInputStream(java)
      val ois = new ObjectInputStream(bis)
      val d_java = ois.readObject().asInstanceOf[HasCommitments] match {
        case d: DATA_WAIT_FOR_FUNDING_CONFIRMED => d.copy(waitingSince = 42000)
        case d: DATA_CLOSING => d.copy(waitingSince = 123456789)
        case d => d
      }
      assert(d_scodec === d_java)
      val scodec2 = ChannelCodecs.stateDataCodec.encode(d_scodec).require
      assert(scodec != scodec2)
      assert(scodec2.size % 8 == 0)
      val d_scodec2 = ChannelCodecs.stateDataCodec.decode(scodec2).require.value
      assert(d_scodec2 == d_java)
      count = count + 1
    }
    println(s"processed $count channels")
  }

It makes little sense committing the migration tests since they occur on two different versions of the code and they only apply at the time of the migration. I prefer documenting them here.

[pm47]

Got rid of this compatibility code.

[pm47]

Got rid of this compatibility code.

[pm47]

I also had this dilemma. I pushed the right button, but I'm really not sure: since the legacy codecs are frozen, shouldn't we remove the non-reg tests?

[t-bast]

shouldn't we remove the non-reg tests?

At least it doesn't hurt to keep them. The way I see it the goal is to completely remove the code of these legacy codecs (for example, X releases after the one where we release the new codecs). We can remove these tests at that point?

If that's the goal, maybe we can put a comment in the code to indicate that strategy.

[t-bast]

I think the testing strategy is sound, and at a high-level the code looks good. Could you squash/rebase and then we can review thoroughly?

[pm47]

At least it doesn't hurt to keep them.

There is a price though: we have several accessible codecs for the same object types, which is a bit error-prone. But we don't use those codecs that often and the risk of using a legacy one by mistake is quite low.

[pm47]

Could you squash/rebase and then we can review thoroughly?

Done. I need to re-run the tests. It just occured to me that #1141 had touched the codecs, so a bit more testing is probably not a bad thing.

[t-bast]

It's surprisingly less painful to review than I had anticipated :)
I hope I didn't miss anything, the migration tests look solid.

[pm47]

6e3414b was less straightforward than I expected. Being in an inner object of the normal codecs, the legacy codecs have transparent access to all codecs which leads to hidden dependencies. I realize now that copy-pasting the old file would have been the safest approach. I started like that but reverted because it prevented me from sharing some codecs... which I now see wasn't a good idea. WDYT?

I've regenerated the random data to support static remote key and successfully re-ran the migration tests.

[pm47]

Tried a different isolation with d052666, and re-ran the migrations tests. I think that design is better.

[t-bast]

LGTM once you've re-done the E2E tests!
