HueGraphics

Interactive 3D Point Cloud Visualization Platform

Upload, process, and explore 3D models with stunning visual effects powered by Three.js

---

Features

• 3D Point Cloud Rendering - Interactive WebGL-based visualization with Three.js
• Kinect v2 Live Streaming - Real-time point cloud capture and visualization via SignalR WebSocket
• EPT Format Support - Efficient point cloud rendering using Entwine Point Tiles
• Camera Controls - Smooth orbit, pan, and zoom controls with camera-controls library
• Dynamic Animations - Chaotic morph-in effects and floating animations
• Detail Level Control - Adjustable point density for performance optimization
• Model Upload API - Upload 3D models (OBJ, FBX, GLTF, etc.) with automatic processing
• Clean Architecture - .NET 10 backend with domain-driven design
• Rust Model Parser - High-performance 3D model to point cloud conversion
• Eidolon Line Theme - Cyberpunk-inspired dark theme with crimson/purple/pink palette
• Docker Support - Full containerization with nginx routing

Project Structure

.
├── src/
│   ├── client/                    # React web application
│   ├── backend/                   # ASP.NET Core API (.NET 10)
│   ├── kinect-bridge/             # Kinect v2 bridge (.NET Framework 4.8)
│   └── model_parser/              # Rust CLI tool
├── scripts/                       # Development and utility scripts
│   ├── run-dev.sh
│   ├── run-dev.bat
│   ├── start-dev.sh
│   └── start-dev.ps1
├── docs/                          # Public documentation
│   ├── GETTING_STARTED.md
│   ├── KINECT_SETUP.md
│   └── START_DEV.md
├── .dev-local/                    # Internal development docs (gitignored)
│   ├── STYLING_GUIDE.md
│   └── upload-models.ps1
└── pointcloud-data/               # Generated point cloud data

Getting Started

Prerequisites

• Node.js 18+ and npm
• .NET 10 SDK (LTS)
• .NET Framework 4.8 (for Kinect bridge, Windows only)
• Rust 1.70+ and Cargo (for model parser)
• Docker and Docker Compose (for containerized deployment)

Documentation

• Getting Started - Comprehensive setup guide
• Kinect Setup - Kinect v2 integration guide
• Start Dev - Quick development startup guide

Local Development

1. Frontend Setup

cd src/client

# Create environment configuration for development
cp .env.example .env.development
# Edit .env.development and set:
# VITE_API_BASE_URL=http://localhost:5000/api

npm install
npm run dev

Frontend will run on http://localhost:5173

Environment Variables:

• VITE_API_BASE_URL: API endpoint URL
  • Development: http://localhost:5000/api (create .env.development)
  • Production: /api (create .env.production, relative path for nginx routing)

2. Backend Setup

cd src/backend/HueGraphics.API

# Copy example config and configure DataPath
cp appsettings.example.json appsettings.json
# Edit appsettings.json and set DataPath to your point cloud data directory

dotnet restore
dotnet run

Backend will run on http://localhost:5000 (Swagger at /swagger)

3. Model Parser Setup

cd src/model_parser
cargo build --release

# Run parser
cargo run -- -i input_model.obj -o output_directory

Docker Deployment

Build and Run with Docker Compose

# Build all containers
docker-compose build

# Start services
docker-compose up -d

# View logs
docker-compose logs -f

# Stop services
docker-compose down

The application will be available at http://localhost:8080

• Frontend: http://localhost:8080/
• API: http://localhost:8080/api/

Environment Variables

Create a .env file in the root directory:

# Point Cloud Data Path
POINTCLOUD_DATA_PATH=/path/to/pointcloud-data

# Upload Authentication
UPLOAD_API_KEY=your-secret-api-key-here

API Endpoints

Point Cloud Endpoints

• GET /api/pointcloud - List all point clouds
• GET /api/pointcloud/{id}/metadata - Get point cloud metadata
• GET /api/pointcloud/{id}/ept-metadata - Get EPT metadata
• GET /api/pointcloud/{id}/ept-tiles/{tileName} - Get EPT tile data

Upload Endpoint (Authenticated)

• POST /api/pointcloud/upload - Upload 3D model for processing
  • Headers: X-API-Key: your-secret-api-key
  • Body: multipart/form-data with ZIP file containing 3D model
  • Form Fields:
    • file: ZIP archive containing 3D model
    • name: Model name (optional)
    • description: Model description (optional)

Upload Example

curl -X POST http://localhost:8080/api/pointcloud/upload \
  -H "X-API-Key: your-secret-api-key" \
  -F "file=@model.zip" \
  -F "name=My Model" \
  -F "description=Test model upload"

Point Cloud Data Structure

{DataPath}/
└── pointcloud-data/
    ├── model-id-1/
    │   ├── ept.json
    │   ├── ept-hierarchy/
    │   └── ept-data/
    │       └── 0-0-0-0.bin
    └── model-id-2/
        ├── ept.json
        └── ...

Model Parser Usage

The Rust model parser converts 3D models to point cloud format:

model_parser -i input_model.obj -o output_directory

Supported Formats:

• OBJ
• FBX
• GLTF/GLB
• STL
• PLY
• 3DS
• And many more (via Assimp)

Point Cloud Controls

• Orbit: Left-click + drag
• Pan: Right-click + drag
• Zoom: Scroll wheel
• Detail Level: Adjust slider to control point density
• Animation: Toggle floating animation effect

Production Deployment

Nginx Configuration

When deploying to a VPS, configure your main nginx to proxy to the containerized application:

server {
    listen 80;
    server_name huegraphics.yourdomain.com;

    location / {
        proxy_pass http://localhost:8080;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_cache_bypass $http_upgrade;
    }
}

Technologies

Frontend

• React 18 - Modern UI framework
• Vite - Lightning-fast build tool
• Three.js - 3D graphics rendering
• camera-controls - Advanced camera manipulation
• React Router v6 - Client-side routing

Backend

• .NET 10 - High-performance web API (LTS)
• SignalR - Real-time WebSocket communication
• Clean Architecture - Separation of concerns
• EPT Support - Binary point cloud format

Kinect Integration

• .NET Framework 4.8 - Bridge for Kinect SDK v2
• Microsoft Kinect SDK v2 - Hardware access
• HTTP/JSON - Bridge to API communication
• Configurable Density - Adjustable point sampling (10%-100%)
• Depth Gradient - Optional depth-based coloring

Model Parser

• Rust - High-performance model processing
• Assimp - 3D model import library

Security

• Upload endpoint requires API key authentication via X-API-Key header
• Configure strong API key in environment variables
• Point cloud data path should be outside web root
• CORS is configured for production domains

Contributing

Contributions are welcome! Please follow these steps:

1. Fork the repository
2. Create a feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add amazing feature')
4. Push to the branch (git push origin feature/amazing-feature)
5. Open a Pull Request

License

This project is licensed under the MIT License.
