Electron by subdavis · Pull Request #397 · Kitware/dive

subdavis · 2020-10-21T21:44:40Z

Electron desktop client

subdavis · 2020-10-27T20:36:05Z

@BryonLewis @AlmightyYakob I'd like to go ahead with merging this. I don't want to diverge from master too far.

Right now it can just open media. No annotations, no save. A lot is missing. I think this is a good incremental addition.

Thoughts?

BryonLewis · 2020-10-27T20:51:47Z

Thoughts?

I'll take a closer look at it tomorrow. I think that having this will help immensely in considering the desktop version and how any future changes could impact it. Part of the idea of having the styles/attributes in a json file located within the dataset is to make it a bit easier for the desktop version as well as exporting from web and importing into Viame Heavy (or the opposite). Less reliance on girder as a service and possibly more reliance on it as a sort of filesystem. I haven't thought through all of it yet, but this will give me some stuff to consider.

BryonLewis

I know this wasn't intended to be tested on Windows but I did anyways. It builds an executable and runs but it seems as though there may be some issues with the folder dialog (Not having a filter so I couldn't see individual image/video files, may be the way the 'directory only' setting behaves) and serving of the images (Looks like it gets the number of frames for the images correct but nothing is displayed). I can take a further in-depth look at it in the future as it could be local windows firewall settings.

Couple of minor things that may change in the future anyways:
Structural:
I don't think we should stick to solely folders for opening datasets. I think we can support opening directories as well as opening individual files. I understand that the Web version is using 'folders' for it's dataset but it's technically a girder folder. For importing data we use individual files which allows you to select a subset of the image frames. Or a single video file in a folder which contains multiple videos. (That's how I noticed, I keep my videos together and went to select one but it wouldn't work).

Very Minor:
This is something I only noticed now because of the length of some of my paths. It should be changed in the Web version as well. The "Launch Annotator" should be a column in a row instead of appended onto the end of the filename. Long file paths (desktop) and folder names (web) cause a wrapping which places the "Launch Annotator" in different places and just doesn't look right.
Very very minor: That default app Icon in ubuntu is nasty.

I have other issues that are related to support with the web version.

BryonLewis

Most of the other stuff works, but I think this issue is a significant one that needs to be edited/fixed so that the web version works.

client/viame-web-common/components/Viewer.vue

subdavis · 2020-10-28T15:36:00Z

I think we can support opening directories as well as opening individual files

This will complicate things. Suppose you have 100 images in a folder. You open 40 of them as one project. You open a different 40 as another. What do you call these projects? How do you indicate which is which? Where do you keep track of these meta-project files, because they can't go in the image directory now. What about annotation files -- you can't know which annotations.csv goes with which subset.

I don't want to support opening individual files unless the customer specifically asks for it. It's not that these problems are unsolveable, they just require extra code and extra testing, and we already have a lot going on.

The desktop app works exactly the same as the web version. You can't put multiple videos in a folder and then open them individually. A folder is a dataset.

With the web version these aren't available on the meta object

Yeah I'll have to fix that

Windows issues

I think we should move the path to a query param though: localhost:2345/api/images?path= seems more appropriate. I'll try this soon.

BryonLewis · 2020-10-28T15:39:06Z

I think we can support opening directories as well as opening individual files

This will complicate things. Suppose you have 100 images in a folder. You open 40 of them as one project. You open a different 40 as another. What do you call these projects? How do you indicate which is which? Where do you keep track of these meta-project files, because they can't go in the image directory now. What about annotation files -- you can't know which annotations.csv goes with which subset.

I don't want to support opening individual files unless the customer specifically asks for it. It's not that these problems are unsolveable, they just require extra code and extra testing, and we already have a lot going on.

The desktop app works exactly the same as the web version. You can't put multiple videos in a folder and then open them individually. A folder is a dataset.

This is my mistake, I forgot that the web version is 'copying' your local data to individual folders instead of just referencing it like the desktop version. What you're saying makes a ton sense keeping that in mind.

subdavis · 2020-10-30T01:14:33Z

Addressed comments in d5ff033.

I squashed a bunch of commits as well.

Windows issues should hopefully be fixed now, but can't test.
Issues with loading datasets on web version are fixed.
Changed to /api/media?path=
Added a trivial vanilla router for node's builtin http server. I briefly considered adding an express.js dependency for robustness, but it seemed like way overkill.
Added mime type filtering, for security or whatever /shrug/

subdavis · 2020-10-30T01:19:44Z

client/platform/web-girder/App.vue

    async function loadMetadata(datasetId: string): Promise<DatasetMeta> {
-      const ds: VIAMEDataset = await root.$store.dispatch('Dataset/load', datasetId);
-      return ds.meta;
+      const dataset: VIAMEDataset = await root.$store.dispatch('Dataset/load', datasetId);


This type coercion is a lie. dispatch() returns an any because we aren't doing proper typescript vuex.

Not a big deal, but also why I don't like vuex. Maybe at some point Jake can show us the righteous path.

BryonLewis

Looks like the previous issues are all fixed. I did a fully docker build and the new version seems to run and load properly with pipelines, saving and everything else.

Windows desktop now can load images/videos properly with either a built version or a yarn serve:electron - built version is a self extracting exe ~55MB in size.

I think at some point we may want to look into a setting that allows Windows users to see the file in a folder they are selecting. Right now it uses a standard file browser but you can only see folder names and if you open a folder you don't see any files inside of it. I imagine there is some workaround for this which I can look into in the future.

Side Note: thanks for the HTML5 Video link, didn't know the history behind ogg and web video.

Trying to get the styling and layout setup Updating some styling Updated styling a bit and added toggling Started updating the editor and connecting it to the attributes endpoint Updating styling and fixing various issues mend mend Electron (#397) * add electron * Add missing api methods * Fix build errors for electron, add to CI * Address comments Update deploy to only Thursday Update base image for girder worker Fixes FPS issue and image caching (#419) * fixing fps and modifying cache * mend Update docker docs (#379) Co-authored-by: Brandon Davis <git@subdavis.com> Update blank.yml (#415) Upgrade to node LTS Co-authored-by: Jacob Nesbitt <jjnesbitt2@gmail.com> Add checkbuild.sh (#425) Add load and save for JSON annotations (#414) * Add load and save for JSON annotations * Relax json file name requirement * SIP * Implement settings, sanity checks, separate loading of datasets * WIP * remove settings page Fix deploy.yml Update day strings (#430) Fix typo in library README Allow setting of arbitrary attributes on video player (#435) * Mute video prop * Allow setting arbitrary attributes Downgrade urllib3 (#439) Fix inverse interpolation (#433) Run pipelines enabled incorrectly (#441) Minor fix to attributes Minor ui fixes Addressing changes Enable pinch zoom on mobile (#440) Co-authored-by: Brandon Davis <git@subdavis.com> Add dummy generators (#438) conversion to using api for attributes editing converted attribute editor and added in additional editing Updating UI interactions

subdavis mentioned this pull request Oct 21, 2020

Electron backend #299

Closed

subdavis force-pushed the electron branch from 5c7f4a0 to d73921f Compare October 21, 2020 21:51

jjnesbitt force-pushed the master branch from 25fe9d2 to bfee525 Compare October 22, 2020 18:36

subdavis force-pushed the electron branch 3 times, most recently from 06ff6b1 to 75a6635 Compare October 27, 2020 20:27

subdavis marked this pull request as ready for review October 27, 2020 20:34

subdavis requested review from BryonLewis and jjnesbitt October 27, 2020 20:40

subdavis force-pushed the electron branch from e5ff3d2 to 07902a8 Compare October 27, 2020 20:58

BryonLewis reviewed Oct 28, 2020

View reviewed changes

BryonLewis requested changes Oct 28, 2020

View reviewed changes

client/viame-web-common/components/Viewer.vue Show resolved Hide resolved

subdavis and others added 4 commits October 29, 2020 20:58

add electron

997c724

Add missing api methods

4c62f1a

Fix build errors for electron, add to CI

437ab6e

Address comments

d5ff033

subdavis force-pushed the electron branch from e8c8148 to d5ff033 Compare October 30, 2020 01:01

subdavis requested a review from BryonLewis October 30, 2020 01:13

subdavis commented Oct 30, 2020

View reviewed changes

BryonLewis approved these changes Oct 30, 2020

View reviewed changes

subdavis merged commit b268bd1 into master Oct 30, 2020

subdavis deleted the electron branch October 30, 2020 12:58
